Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: drakat
  • Model Number: DK-8108
  • Power: Electronic, 4*1.5V Size AA batteries
  • Usage: Network Lan cable tester
  • Product: Cable Tester
  • Function: Test & Measure Lan cable
  • Display: LCD (Wiremap)
  • Cable type: STP UTP Ca5e Cat6
  • Operation: Easy
  • Color: Dark Gray
  • Warranty period: 1 year
  • Certificate: CE & RoHS

Packaging & Delivery

Packaging Details 1 PC/BOX, 25 PCS/CTN
Delivery Time Shipped in 7 days after payment

Product Overviews



UTP STP Cat5E/Cat6 RJ45 Lan Network Cable Length Tester DK-8108

1. Measure network cable length to an end or broken point.

2. Check wiring error in STP UTP 5E, 6E, coaxial cable, such as open circuit,short circuit, jumper wire, reverse connection.

3. Display by big LCD, with clear wiremap.

4. Automatically time-delay shut off.

5. Length Calibration: User can set self-calibration factor by a given length cable (The length of calibrating cable needs to be more than 5M )

6. Self-checking and automatically compensate any change in battery capacity or ambient temperature.



Technical Parameters



DK-8108

Indicator

LCD 61.5x25.2 mm

Type of cable tested

Lan cable (5E, 6E), coaxial cable

Compatible connectors

RJ45

Tone frequency

225 Hz

Max. distance of cable map

1-305m (3-1000ft) for twisted pair

Calibration accuracy

97% (± 0.5m or ± 1.5 ft) (calibrating cable > 5 M)

Calibration accuracy

5% (± 0.5m or ± 1.5 ft) (AMP, AT&T Class 5 cable)

Max. working current

Less than 70mA

Display

LCD display

Unit of Measurement

Meter (M) or Feet (FT)

Low battery display

LCD ( 6.5V)

Voltage protection

AC 60V/DC 42V

Battery Type

DC 4x1.5v

Working Ambient Temperature

-10°C to 60°C

Automatic Time-delay Shut Off Time

30 minutes

Dimension of Transmitter

18.4*8.4*4.6 cm (7.2*3.3*1.8 in)

Dimension of Remote Unit

7.8*3.3*2.2 cm (3.1*1.3*0.9 in)

Detailed Images


Packaging & Shipping

Each item includes:

1 pc * Tester

1 pc * Remote Unit

1 pc * Black cloth bag

1 pc * English manual

1 pc * Color bag
